| Place of Origin: | China |
| Brand Name: | Haihao |
| Certification: | CE ISO |
Multi-Zone Cleanroom Management Touch Panel | Centralized HVAC & Facility Monitoring System
Description:
Centralized Facility Control: Provides an intuitive interface to monitor and manage multiple cleanroom zones, HVAC systems, and environmental alarms from a single point.
Real-Time Data Visualization: View live graphs and trends of differential pressure, temperature, humidity, and air flow velocities for immediate response to deviations.
User Access Control: Implement secure, role-based login to prevent unauthorized changes to critical system setpoints and ensure data integrity.
Alarm Management System: Features visual and audible alarms with event logging to maintain compliance and quickly address any process or environmental excursions.
Application: Essential for large-scale facilities in pharmaceuticals, medical device manufacturing, and aerospace industries.
| Touch panel control panel parameters | ||||
| P/N | Type | External Dimension W*H*D(mm) |
General information panel/LED Information panel sizeW*H(mm) |
Opening size W*H(mm) |
| LHH-6(2)-01 | 24-inch touch panel control panel(stainless steel closure) |
818*519*160 | 735*436 | 748*449 |
| LHH-6(2)-02 | 27-inch touch panel control panel(stainless steel closure) |
935*538*160 | 852*455 | 865*465 |
| LHH-6(2)-03 | 32-inch touch panel control panel(stainless steel closure) |
992*595*160 | 909*513 | 922*525 |
| LHH-6(2)-04 | Integrated 24-inch touch panel control panel(stainless steel finish) |
818*958*300 | 735*436 | 756*889 |
| LHH-6(2)-05 | Integrated 27-inch touch panel control panel(stainless steel finish) |
935*977*300 | 852*455 | 873*908 |
| LHH-6(2)-06 | ntegrated 32-inch touch panel control panel (stainless stel finish) |
992*1035*300 | 909*513 | 930*966 |
