| Place of Origin: | China |
| Brand Name: | Haihao |
| Certification: | CE ISO |
High-Efficiency Laminar Flow Ceiling System - Cleanroom Grade (Specify Size, e.g., 2.4m x 1.2m)
Product features
Achieve Critical Cleanliness Levels: Our laminar flow ceiling is the essential solution for establishing and maintaining stringent ISO Classified environments (Specify target class, e.g., ISO 3-5). It provides a continuous downward curtain of purified air, sweeping contaminants away from critical work zones.
Core Component - Superior Filtration: At the heart of the system are meticulously tested and certified HEPA (High-Efficiency Particulate Air) or ULPA (Ultra-Low Penetration Air) filters (Specify type and efficiency, e.g., H14 HEPA, 99.995% @ 0.3µm). Guaranteed integrity for maximum particle capture.
Optimized Airflow Performance: Engineered diffuser design ensures exceptionally uniform air velocity (Specify range if possible, e.g., 0.35-0.55 m/s ±20%) and minimal turbulence, crucial for protecting sensitive products and processes.
Built to Last: Constructed from high-quality, non-shedding materials. Standard frames are (Specify, e.g., anodized aluminum), with options for (Specify, e.g., stainless steel, anti-static coatings) for specific industry requirements (e.g., semiconductor, pharmaceutical).
Flexible & User-Friendly: Available in standard modular sizes (List common sizes, e.g., 600x600mm, 1200x600mm, 1200x1200mm) or custom configurations. Designed for straightforward installation and future filter replacement access.
Trusted Compliance: Supports adherence to cleanroom standards (ISO 14644), GMP guidelines, and other relevant regulatory frameworks.
| P/N | Type | External Dimension WH*D(mm) |
Efficient Dimension W*H*D(mm) |
Efficient QTY(PC) |
| LHH-4-01 | I level laminar flow purification air supply ceiling |
2600*2400*400 | 1196*346*69 | 4 |
| 946*462*69 | 2 | |||
| LHH-4-02 | l level laminar flow purification air supply ceiling |
2600*1800*400 | 1196*546*69 | 4 |
| 946*462*69 | 2 | |||
| LHH-4-03 | Ⅲ level laminar flow purification air supply ceiling |
2600*1400*400 | 1196*676*69 | 4 |
| 946*366*69 | 4 | |||
| LHH-4-04 | I level Ophthalmology laminar flow purification ceiling |
1500*1500*400 | 1196*366*69 | 2 |
| 462*366*69 | 2 |
